EVOSCAN EVO X / 4B11T Fuel flow report
Red Mitsubishi Lancer Evolution X on a New Zealand road

EVOSCAN TECH / FUEL SYSTEM PLANNING

MORE POWER.
STARTS WITH
ENOUGH FUEL.

Build a clearer picture of your Evo X fuel system. Explore pump supply, engine demand and the fuel that still needs a way back to the tank.

BUILD YOUR REPORT
01 / THE BIG PICTURESCROLL TO EXPLORE

FOLLOW THE FUEL

IN UNDER
PRESSURE.
BACK WITH
RESERVE.

A pump's headline flow rating is only the beginning. Boost raises the pressure it works against. Your engine uses part of the supply; the rest returns to the tank.

THE RETURN-STYLE FUEL SYSTEM

Fuel supply and return path Fuel travels from the tank and pump to the rail. The injectors deliver fuel to the engine. The regulator sends the unused fuel back to the tank. TANK + PUMP The supply RAIL + FPR Pressure control FUEL SUPPLIED UNDER PRESSURE → ← UNUSED FUEL RETURNS TO THE TANK To injectors

SupplyWhat the pump delivers at pressure.

DemandWhat the engine needs at your target.

ReturnWhat's left to go back to the tank.

02 / SUPPLY · DEMAND · RETURNMEET THE COMBINATIONS

FROM FACTORY HARDWARE TO A FULL FUEL SYSTEM

TEN SETUPS.
ONE CLEAR
COMPARISON.

Set your power, boost and fuel. See the same engine demand applied to every combination, then open a setup to inspect the numbers or swap its parts.

EXPLORE THE FUEL FLOW REPORT
  1. 01
    SET YOUR TARGET

    Power, fuel, boost, voltage and injectors.

  2. 02
    COMPARE THE HEADROOM

    Pump reserve and injector duty, side by side.

  3. 03
    LOOK AT THE WHOLE SYSTEM

    Supply at peak boost and the return path at idle.

03 / MAKE THE NUMBERS YOURSINTERACTIVE REPORT BELOW
EVOSCAN / INTERACTIVE TOOLBACK TO INTRO ↑

Evo X 4B11T fuel flow report

Supply flow, return flow and headroom for ten pump, rail and regulator combinations. Set your power target and boost, and every combination is recalculated against the same engine demand.

Your target

Peak-power conditions. All Evo X regulators here are manifold-referenced 1:1, so rail pressure at peak boost is base pressure plus boost.

Power target450 whp
Fuel93 octane
BSFC (lb/hp·hr)0.60
Peak boost28 psi
Base pressure (adjustable regulators)43.5 psi
The OEM regulator stays fixed at about 43 psi.
Voltage at the pump13.5 V
Injectors1065 cc
Max duty cycle85%
Pump reserve you want at peak15%
Share of the flow reaching the rail that should still be returning to the tank at peak power.
Venturi draw, Radium hangers

Where each combination tops out

Power each system supports before the pump runs out of reserve or the injectors hit their duty ceiling, whichever comes first. The black tick is your target.

The ten combinations

Each bar is the pump's output at peak-boost rail pressure: what the engine burns, what returns to the tank, and any shortfall. The tick is your reserve floor. Open a combination for the full numbers, or swap parts.

Taken by the venturi jet pump Burned by the engine Returned to tank Shortfall Reserve floor

Pump flow against pressure

Flow at your pump voltage for every pump in use above. The vertical line is rail pressure at peak boost; the amber line is what the engine needs, and the grey line adds the venturi draw a Radium hanger takes off the top. A pump only works where its curve sits above the crossing.

How the numbers are made

Planning estimates for comparing options. Confirm with a fuel pressure gauge and wideband on the car before leaning on any of these figures.
